What a solar project or a solar power plant is built from: Deye three-phase string inverters to 136 kW, hybrids to 80 kW, storage to 4,340 kWh.
A solar project for a factory roof and a solar power plant on open ground are built from the same three things: three-phase string inverters, storage where the site needs it, and enough of each in parallel. This page lists the units in our catalogue rated for that scale, with the figures their spec tables state.
Products mentioned in this article
Deye 215 kWh 768 V Lithium Solar Battery MS-G215 – Commercial & Industrial Energy Storage Cabinet
- System Energy:215 kWh
- Operating Voltage:660-876 V
Deye 50 kW Three-Phase String Solar Inverter SUN-50K-G04
- Rated AC Output Active Power:50000 W
- Max. Efficiency:98.7 %
Deye 100 kW Three-Phase String Solar Inverter SUN-100K-G03
- Rated AC Output Active Power:100000 W
- Max. Efficiency:98.8 %
String inverters for a solar power plant
An export-only plant is an array of on-grid string inverters. These three mark the bottom, the middle and the top of the three-phase range; 136 kW is the highest rated power of any inverter we list.
| Model | Rated power | MPPTs | Max. PV input power | Max. PV input voltage | Weight |
|---|---|---|---|---|---|
| SUN-50K-G04 | 50 kW | 4 | 65 kW | 1100 V | 39 kg |
| SUN-100K-G03 | 100 kW | 6 | 150 kW | 1000 V | 81 kg |
| SUN-136K-G01P3 | 136 kW | 8 | 204 kW | 1100 V | 103 kg |
All three connect 3L+N+PE at 220/380 V or 230/400 V, carry an IP65 enclosure and state zero export support, which is the row to read where the utility does not accept export. Maximum efficiency is 98.7% on the SUN-50K-G04 and 98.8% on the other two.
Hybrid inverters for a solar project with storage
Where the project has to carry load through an outage or work beside a generator, the SG02HP3 hybrids take the place of the string inverter. The SUN-60K-SG02HP3 and the SUN-80K-SG02HP3 are rated 60 kW and 80 kW; both accept a battery between 160 V and 1000 V, charge at 80+80 A, run six MPPTs and state support for a diesel generator. Ten units work in parallel, and the SUN-80K-SG02HP3 has two battery inputs and takes up to 128 kW of PV.
Storage cabinets and containers
Storage at project scale comes as a floor-mounted cabinet or a container, all on LiFePO4 cells. Two of the cabinets and one container carry their own MPPT inputs, so the array connects to the storage unit directly.
| Model | Energy | Rated DC power | Max. PV input power | Enclosure |
|---|---|---|---|---|
| GE-F120 | 122.8 kWh | 50 kW | 65 kW | IP55 |
| MS-G215 | 215 kWh | 100 kW | no PV input | IP54 |
| MS-GS215-2H3 | 215 kWh | 100 kW | 200 kW | IP54 |
| WS-GS2000-2H3 | 2,057 kWh | 1,000 kW | 1,280 kW | IP54 |
| WS-L4300-2H3 | 4,340 kWh | not stated | no PV input | IP55 |
The GE-F120 and the MS-GS215-2H3 run ten units in parallel and the MS-G215 twelve. The two WS containers share one footprint, 6058 x 2438 x 2896 mm; the WS-GS2000-2H3 has 64 MPPTs and the WS-L4300-2H3 is liquid cooled.
Three questions that pick the unit
- Does the site export everything it generates? Then it is a string-inverter plant: divide the array by the max. PV input power of the rating you choose.
- Does it need backup or a generator beside it? Then it is a hybrid, and the battery voltage range decides which stack it takes.
- Is the storage larger than a row of cabinets in parallel? Then it is a container, and the footprint above is the pad to pour.
Ordering for Saudi Arabia and the UAE
Every unit above has its own page with the full spec table, and the Saudi Arabia and UAE editions of each page state the price in SAR and in AED. Order online: every model in the catalogue shows its price, and checkout takes a minute.
Frequently Asked Questions
What is the largest Deye inverter for a solar power plant?
Can a Deye solar project run without exporting to the grid?
How much storage can one Deye unit hold?
